Serverless Master-Replica database example using MySQL

In this example exercise, we will build a MySQL SaaS with serverless capabilities enabled by Omnistrate and a master-replica architecture. Let's start with the simplest example and then the complete one, we will then break down the complete example to fully understand how it works.

Hello world MySQL SaaS

Here is a hello world version of MySQL powered by bitnami images:

version: "3"

services:
  Master:
    image: 'docker.io/bitnami/mysql:8.0.36'
    ports:
      - '3306'
    volumes:
      - ./data:/var/lib/mysql
    environment:
      - MYSQL_REPLICATION_MODE=master
      - MYSQL_REPLICATION_USER=repl_user
      - MYSQL_REPLICATION_PASSWORD=xFAwjmUcECktqL
      - MYSQL_PASSWORD=password
      - MYSQL_DATABASE=database
      - MYSQL_USER=username
      - MYSQL_ROOT_PASSWORD=root
      - SECURITY_CONTEXT_USER_ID=0
      - SECURITY_CONTEXT_FS_GROUP=0
      - SECURITY_CONTEXT_GROUP_ID=0

  Replica:
    image: 'docker.io/bitnami/mysql:8.0.36'
    ports:
      - '3306'
    volumes:
      - ./data:/var/lib/mysql
    environment:
      - MYSQL_MASTER_HOST=localhost
      - MYSQL_REPLICATION_MODE=slave
      - MYSQL_REPLICATION_USER=repl_user
      - MYSQL_REPLICATION_PASSWORD=xFAwjmUcECktqL
      - MYSQL_USER=username
      - MYSQL_DATABASE=database
      - MYSQL_MASTER_ROOT_PASSWORD=root
      - MYSQL_MASTER_PORT_NUMBER=3306
      - SECURITY_CONTEXT_USER_ID=0
      - SECURITY_CONTEXT_FS_GROUP=0
      - SECURITY_CONTEXT_GROUP_ID=0

This is the simplest version of a MySQL SaaS with a master-replica architecture. You can run this with docker-compose up and you will have a master and a replica running on your local machine.

In this case, the master-replica setup is achieved by leveraging the environment variables only on both the master and the replica side, setting up replication mode, user, password, and other MySQL environment variables.

    environment:
      - MYSQL_MASTER_HOST=localhost
      - MYSQL_REPLICATION_MODE=slave
      - MYSQL_REPLICATION_USER=repl_user
      - MYSQL_REPLICATION_PASSWORD=xFAwjmUcECktqL
      - MYSQL_USER=username
      - MYSQL_DATABASE=database
      - MYSQL_MASTER_ROOT_PASSWORD=root
      - MYSQL_MASTER_PORT_NUMBER=3306
      - SECURITY_CONTEXT_USER_ID=0
      - SECURITY_CONTEXT_FS_GROUP=0
      - SECURITY_CONTEXT_GROUP_ID=0

On a sidenote, whenever you define your services and such services have a password or sensitive fields in their environment variables, you should random generated them and use a secret manager to store these values. You can then inject them into your services. MYSQL_REPLICATION_PASSWORD=xFAwjmUcECktqL is an example of a sensitive field that should be stored in a secret manager.

Serverless MySQL SaaS on Omnistrate

Now let's add some Omnistrate features to the recipe on top of making your MySQL serverless.

version: "3"

x-omnistrate-integrations:
  - omnistrateLogging
  - omnistrateMetrics

services:
  Master:
    image: 'docker.io/bitnami/mysql:8.1.0'
    ports:
      - '3306'
    volumes:
      - ./data:/var/lib/mysql
    x-omnistrate-compute:
      instanceTypes:
        - cloudProvider: aws
          apiParam: masterInstanceType
        - cloudProvider: gcp
          apiParam: masterInstanceType
    x-omnistrate-capabilities:
      serverlessConfiguration:
        targetPort: 3306
        enableAutoStop: true
        minimumNodesInPool: 1
    environment:
      - MYSQL_REPLICATION_MODE=master
      - MYSQL_REPLICATION_USER=repl_user
      - MYSQL_REPLICATION_PASSWORD=xFAwjmUcECktqL
      - MYSQL_PASSWORD=$parameterGroup.var.mysqlPassword
      - MYSQL_DATABASE=$parameterGroup.var.mysqlDatabase
      - MYSQL_USER=$parameterGroup.var.mysqlUsername
      - MYSQL_ROOT_PASSWORD=$parameterGroup.var.mysqlRootPassword
      - SECURITY_CONTEXT_USER_ID=1001
      - SECURITY_CONTEXT_FS_GROUP=1001
      - SECURITY_CONTEXT_GROUP_ID=0
    x-omnistrate-api-params:
      - key: masterInstanceType
        description: Master Instance Type
        name: Master Instance Type
        type: String
        modifiable: true
        required: true
        export: true
      - key: parameterGroupId
        description: Master configuration
        name: Parameter Group Id
        dependentResourceKey: ParameterGroup
        type: Resource
        modifiable: true
        required: true
        export: true

  Replica:
    image: 'docker.io/bitnami/mysql:8.1.0'
    ports:
      - '3306'
    volumes:
      - ./data:/var/lib/mysql
    x-omnistrate-compute:
      replicaCountAPIParam: numReadReplicas
      instanceTypes:
        - cloudProvider: aws
          apiParam: replicaInstanceType
        - cloudProvider: gcp
          apiParam: replicaInstanceType
    x-omnistrate-capabilities:
      enableMultiZone: true
      endpointPerReplica: true
      autoscaling:
        minReplicas: 1
        maxReplicas: 5
        idleMinutesBeforeScalingDown: 2
        idleThreshold: 20
        overUtilizedMinutesBeforeScalingUp: 3
        overUtilizedThreshold: 80
      serverlessConfiguration:
        targetPort: 3306
        enableAutoStop: true
        minimumNodesInPool: 1
    environment:
      - MYSQL_MASTER_HOST=$master.sys.network.externalClusterServerlessEndpoint.endpointName
      - MYSQL_REPLICATION_MODE=slave
      - MYSQL_REPLICATION_USER=repl_user
      - MYSQL_REPLICATION_PASSWORD=xFAwjmUcECktqL
      - MYSQL_USER=$parameterGroup.var.mysqlUsername
      - MYSQL_PASSWORD=$parameterGroup.var.mysqlPassword
      - MYSQL_DATABASE=$parameterGroup.var.mysqlDatabase
      - MYSQL_MASTER_ROOT_PASSWORD=$parameterGroup.var.mysqlRootPassword
      - MYSQL_MASTER_PORT_NUMBER=$master.sys.network.externalClusterServerlessEndpoint.openPorts[0]
      - SECURITY_CONTEXT_USER_ID=1001
      - SECURITY_CONTEXT_FS_GROUP=1001
      - SECURITY_CONTEXT_GROUP_ID=0
    x-omnistrate-api-params:
      - key: replicaInstanceType
        description: Replica Instance Type
        name: Replica Instance Type
        type: String
        modifiable: true
        required: true
        export: true
      - key: masterInstanceId
        description: Instance Id of the Master to connect
        name: Master Instance Id
        dependentResourceKey: Master
        type: Resource
        modifiable: true
        required: true
        export: true
      - key: parameterGroupId
        description: Replica configuration
        name: Parameter Group Id
        dependentResourceKey: ParameterGroup
        type: Resource
        modifiable: true
        required: true
        export: true
      - key: numReadReplicas
        description: Number of Read Replicas
        name: Number of Read Replicas
        type: Float64
        modifiable: true
        required: false
        export: true
        defaultValue: "1"
        limits:
          min: 1
          max: 10

  ParameterGroup:
    image: omnistrate/noop
    x-omnistrate-api-params:
      - key: mysqlUsername
        description: Default MySQL Username
        name: Username
        type: String
        modifiable: false
        required: true
        export: true
      - key: mysqlPassword
        description: Default MySQL Password
        name: Password
        type: String
        modifiable: false
        required: true
        export: false
      - key: mysqlDatabase
        description: Default MySQL Name
        name: Default Database
        type: String
        modifiable: false
        required: true
        export: true
      - key: mysqlRootPassword
        description: Root Password
        name: Root DB Password
        type: String
        modifiable: false
        required: true
        export: false

This is the final result!

It could be a lot to digest so let's break it down.

We've added the x-omnistrate-integrations section to enable logging and metrics for your customers, as follows:

x-omnistrate-integrations:
  - omnistrateLogging
  - omnistrateMetrics

We've also added the x-omnistrate-compute section and a custom parameter x-omnistrate-api-params to configure the instance types for the master and replica(s).

Here how to enable the instanceType on master:

    x-omnistrate-compute:
      instanceTypes:
        - cloudProvider: aws
          apiParam: masterInstanceType
        - cloudProvider: gcp
          apiParam: masterInstanceType
    x-omnistrate-api-params:
      - key: masterInstanceType
        description: Master Instance Type
        name: Master Instance Type
        type: String
        modifiable: true
        required: true
        export: true

Now a very interesting one.

    x-omnistrate-capabilities:
      enableMultiZone: true
      endpointPerReplica: true
      autoscaling:
        minReplicas: 1
        maxReplicas: 5
        idleMinutesBeforeScalingDown: 2
        idleThreshold: 20
        overUtilizedMinutesBeforeScalingUp: 3
        overUtilizedThreshold: 80
      serverlessConfiguration:
        targetPort: 3306
        enableAutoStop: true
        minimumNodesInPool: 1

Thanks to this piece of x-omnistrate-capabilities configuration we've enabled multi-zone support, endpoint per replica, autoscaling with a 1 to 5 setup.

Serverless capabilities are also there, running on the MySQL service port, with autostop enabled and a warmpool that counts 1 node. You can (and should) adjust these parameters to better fit your needs.

On top of this, to harden your service and avoid confusion for your users we made the hierarchical structure of this Master-Replica setup, pretty obvious.

Omnistrate linking management is a powerful feature that allows you to create a strong link between resources, enforced on the access side UI as well. In this case, we've created a link between the Master and Replica services.

      - key: masterInstanceId
        description: Instance Id of the Master to connect
        name: Master Instance Id
        dependentResourceKey: Master
        type: Resource
        modifiable: true
        required: true
        export: true

This dependentResourceKey parameter means that when someone is creating a Replica they need to provide the Master instance id related to it, otherwise, the Replica cannot be created and the control plane for your service will enforce this.

We have also created the same link with our parameter group component on both the Master and Replica services.

This is how we've done it for the Master component:

      - key: parameterGroupId
        description: Master configuration
        name: Parameter Group Id
        dependentResourceKey: ParameterGroup
        type: Resource
        modifiable: true
        required: true
        export: true

This ensures that both Master and Replica have their own assigned ParameterGroup or they cannot be created. We defined the ParameterGroup as follows:

  ParameterGroup:
    image: omnistrate/noop
    x-omnistrate-api-params:
      - key: mysqlUsername
        description: Default MySQL Username
        name: Username
        type: String
        modifiable: false
        required: true
        export: true
      - key: mysqlPassword
        description: Default MySQL Password
        name: Password
        type: String
        modifiable: false
        required: true
        export: false
      - key: mysqlDatabase
        description: Default MySQL Name
        name: Default Database
        type: String
        modifiable: false
        required: true
        export: true
      - key: mysqlRootPassword
        description: Root Password
        name: Root DB Password
        type: String
        modifiable: false
        required: true
        export: false

The parameter group is a passive component that is used to store the configuration of the MySQL service. It's a way to centralize the configuration of the MySQL service and make it reusable across different services. It's useful to avoid duplication and to enforce a standard configuration at the same time.

To create such a component we've used the omnistrate/noop image, which is a passive kind of image that does nothing (no-operations) but is useful to create such components that are not defining running services.

Note: you can call such components in your preferred way based on their usage, in this case, we've called it ParameterGroup but you can call it MySpecialConfig or MyAwesomeConfig or whatever you want.

At the end of the day we've added a lot more than just serverless capabilities. We've added the ability to configure the instance types, the number of replicas, the ability to configure the MySQL environment variables via our API params, autoscaling, logging and metrics (enabled by OpenTelemetry), plus multi-zone support and endpoint for our replica(s).

We took the compose spec and added our platform capabilities to create a complete MySQL SaaS.

Here is how it looks like:

Watch the video

Try it yourself using the latest yaml configuration provided.
